WF-10T Electric High Lift Head Centrifugal Oil Transfer Gear Pump

Product Description

♦♦ Detailed Introduction

1. It is circulation vortex pump to transfer high temperature medium by pip type. The medium is liquid without the particle and fiber, such as water, conduction oil and glycol and so on.
2. The equipment has the advantages of high-temperature resistance, simple construction, stable performance, wide usage scope and so on.
3. This pump widely used in small precision mold temperature controller, medical sterilization , small hot oil boiler , supplying water system of the boiler , testing equipment , thermostatic oil bath and other

♦♦ Technical Parameter

Type

Flange

Diameter

Motor

(kw/Hp)

Voltage

(V)

Frequency

(Hz)

Rotation speed

(r/min)

MAX Head lift

(m)

Capacity

(L/min)

Weight

(kg)

WF-10T

3/4” or 1”

0.75/1

3phase-380

50

2760

55

50

11

Other Models

Type

Flange

Diameter

Motor

(kw/Hp)

Voltage

(V)

Frequency

(Hz)

Rotation speed

(r/min)

MAX Head

(m)

Capacity

(L/min)

Weight

(kg)

WF-10

3/4”(DN20)

1”(DN25)

0.75/1

3phase-380

50

2760

55

50

12.5

WF-10S

3/4”(DN20)

1”(DN25)

0.75/1

1phase-220

50

2760

55

50

12.5

♦♦ Material of Oil Transfer Gear Pump

1

Pump Body

Cast iron

2

Axis

SUS

3

Sealing Material

Carborundum or alloy or ceramic + graphite

+ high-temperature resistance rubber

4

Impeller

Copper

5

Insulation Grade

F

6

IP Grade

IP54

♦♦ Installing Drawing
♦♦ Performance Chart
♦♦ Feature

1. High- temperature resistance , small volume, saving installing room
2. Low noisy , low energy , stable performance ,high flowing speed
3. Easy to repaire, saving cost

♦♦ Application Scope

1. Clean water , hot water and other circulation system
2. Feeding water system for the high and middle pressure small boiler , offering oil system in the oil boiler
3. Receiving water system for boiler
4. Transferring the liquid without particle for high temperature circulation

♦♦ Using Condition

High Temperature Water

+ 5 ℃ ~ + 95 ℃

High Temperature Conductivity Oil

+ 5℃ ~ + 200℃

Glycol

-30 ℃ ~ + 180 ℃

The Working Environment Temperature

-5℃ ~ + 40℃

♦♦ The Testing Base

The above characteristic testing is based on the water transferring with the normal speed under 20 degrees. The error of the capacity and head is about 10%, characters ‘error is about 10%. The pump characters change according to the difference of the liquid mediums’ proportion and density.

♦♦ Product
Not your want? Pls Click the below for more Pumps!
MDW Magnetic Drive Type Vortex Pump WL Leakage Free Hot Water Hot Oil Vertical Vortex Pump
WD German Technology Hot Water Hot Oil Vortex Pump WM Economical Hot Water Hot Oil Vortex Pump
WF High Precision Hot Water Hot Oil Vortex Pump WG High Pressure Hot Water Hot Oil Vortex Pump
RGP High Lift Centrifugal Pump RGZ Fast Flow Rate Centrifugal Pump
WRY-H Coupled High Temperature Oil Pump
♦♦ Certificate

Packaging & Shipping
♦♦ Trade Details

MOQ

1 sets Oil Transfer Gear Pump

Port

Shanghai

Packaging

Standard wooden case and carbon

Payment

L/C, T/T, Western Union

Delivery

Within 7 days after receiving deposit for Oil Transfer Gear Pump

Shippment

By air, by sea, by truck, express

Our Services
♦♦ Our Service

1. According to your requirements, we supply you the high quality Oil Transfer Gear Pump with the best price, more better suggestions are offered to you.
2. We will arrange the delivery the Oil Transfer Gear Pump when receiving your deposite. Generally speaking, It will taked about 5 -10 days to arrange.
3. The warranty period is 1 years except the wear parts. We will supply you free replaced parts (except wear parts ) if the Oil Transfer Gear Pump is damaged caused by the machine itself during warranty period . For online instruction service is free. For the wear parts, we will supply you by the lowest price if necessary.
